71M6515H Demo Board User’s Manual
PHADJ ? 2 ( 1 ? 2 ? 9 ) cos( 2 π f 0 T ))
PHADJ ( 2 + 2
CAL _ I NEW =
CAL _ I
A XI
1 +
2
? 20
1
? 20
1 ? 2 ( 1 ? 2 ? 9 ) cos( 2 π f 0 T ) + ( 1 ? 2 ? 9 ) 2
2.1.5
CALIBRATION WITH FIVE MEASUREMENTS
The five measurement method provides more orthogonality between the gain and phase error derivations.
This method involves measuring E V , E 0 , E 180 , E 60 , and E 300 . Again, set all calibration factors to nominal, i.e.
CAL_IA = 16384, CAL_VA = 16384, PHADJ_A = 0.
First, calculate A XV from E V :
1.
A XV = E V + 1
Calculate A XI from E 0 and E 180 :
2.
E 0 =
IV A XV A XI cos( 0 ? φ S )
IV cos( 0 )
? 1 = A XV A XI cos( φ S ) ? 1
3.
E 180 =
IV A XV A XI cos(180 ? φ S )
IV cos( 180 )
? 1 = A XV A XI cos( φ S ) ? 1
4.
E 0 + E 180 = 2 A XV A XI cos( φ S ) ? 2
5.
A XV A XI =
E 0 + E 180 + 2
2 cos( φ S )
6.
A XI =
( E 0 + E 180 ) 2 + 1
A XV cos( φ S )
Use above results along with E 60 and E 300 to calculate φ S .
7.
E 60 =
IV A XV A XI cos( 60 ? φ S )
IV cos( 60 )
? 1
= A XV A XI cos( φ S ) + A XV A XI tan( 60 ) sin( φ S ) ? 1
8.
E 300 =
IV A XV A XI cos( ? 60 ? φ S )
IV cos( ? 60 )
? 1
= A XV A XI cos( φ S ) ? A XV A XI tan( 60 ) sin( φ S ) ? 1
Subtract 8 from 7
9.
E 60 ? E 300 = 2 A XV A XI tan( 60 ) sin( φ S )
use equation 5:
10.
E 60 ? E 300 =
E 0 + E 180 + 2
cos( φ S )
tan( 60 ) sin( φ S )
11.
E 60 ? E 300 = ( E 0 + E 180 + 2 ) tan( 60 ) tan( φ S )
φ S = tan ? 1 ? ?
?
12.
Revision 2.0
?
?
( E 60 ? E 300 ) ?
tan( 60 )( E 0 + E 180 + 2 ) ? ?
? Copyright 2005 TERIDIAN Semiconductor Corporation
30 of 66
